Specification

Material :

• Fixture Body: High-quality graphite plate

• Electrical Contacts: Gold-plated or copper contacts for optimal electrical conductivity

• Sealing Gaskets: EPDM, Viton, or other suitable materials for effective sealing

Components :

• Fixture Body: Rigid frame to securely hold the fuel cell

• Clamping Mechanism: Adjustable clamps to ensure consistent pressure and contact

• Electrical Contacts: Configurable contacts for precise measurements

• Temperature Control Ports: Integrated ports for temperature sensors and heating/cooling elements

• Gas Flow Channels: Designed to ensure uniform distribution of reactants

• Sealing Gaskets: Ensures no leakage and maintains the integrity of the test environment

Operating Conditions :

• Temperature Range: -20°C to 80°C (varies with materials used)

• Pressure Range: Suitable for atmospheric pressure to slight positive pressure

Working Area Options :

• 3 cm x 3 cm (9 cm²)

• 5 cm x 5 cm (25 cm²)

Applications

• Research and Development: Ideal for testing new fuel cell materials, designs, and specifications.

• Quality Control: Used for routine testing of fuel cells in manufacturing and production environments.

• Performance Evaluation: Suitable for evaluating the performance and durability of fuel cells under various conditions.

• Educational Use: Utilized in academic settings for teaching and demonstrating principles of fuel cell technology.

• Industrial Applications: Applied in the development and optimization of fuel cell systems for various industrial uses.
